- USE KEY 1 TO TAKE PICTURE.
- WITH SHORT PRESS ON KEY 2, LIGHT WILL BE TURNED ON.
- WITH LONG PRESS ON KEY 2, LIGHT WILL BE TURNED OFF.
STEPS TO INSTALL SOFTWARE:
1). PUT THE CD INTO THE ROM
2) OPEN FILE TO INSTALL SOFTWARE OF DENTAL USB
3). START TO INSTALL SOFTWARE.
4). WHEN FINISH INSTALLMENT, "DENTAL USB" AND "AMCAPC" ICONS WILL APPEAR.
5). CONNECT THE USB CAMERA TO COMPUTER.
START TO USE SOFTWARE:
1). DOUBLE CLICK ON DENTAL USB TO OPEN SOFTWARE, CLICK THE MIDDLE OF PICTURE TO ENTER "CUSTOMER INFORMATION" MENU.
ADD: PRESS TO CREATE CUSTOMER FILE.
SEARCH: SEARCH FILE RECORD.
EXIT: PRESS TO TO EXIT THE SOFTWARE.
EDIT: PRESS TO UPDATE THE CUSTOMER FILE, AFTER EDIT THE INFORMATION.
DELETE: DELETE THE FILE, WHICH IS CHOSEN.
ENTER: ENTER THE CHECK UP INTERFACE.
2). INPUT CUSTOMER INFORMATION, CLICK "ADD" TO CREATE CUSTOMER FILE.
- CLICK ON CAPTURE SIZE TO CHOOSE THE SIZE OF PICTURE.
- CLICK ON SETTING TO SET THE PARAMETER OF VIDEO OR CAMERA.
3). SELECT/CANCEL MENU - CLICK "SELECT/CANCEL" TO CHOOSE PICTURE OR CANCEL SELECTION.
4). DELETE MENU - SELECT PICTURE, THEN PRESS "DELETE" TO DELETE PICTURE.
5). SAVE AS MENU - CHOOSE PICTURE THEN CLICK "SAVE AS" TO SAVE PICTURE TO SPECIFIED FILE.
6). COMPARE MENU
- CHOOSE PICTURE THEN CLICK "COMPARE" TO ENTER COMPARE MODE.
- CLICK ESC OR DOUBLE CLICK TO CLOSE COMPARE MODE.
7). PRINT IMAGE MENU
- CHOOSE PICTURE TO CLICK "PRINT IMAGE", THEN ENTER PRINT MODE, AFTER ENTERING THE PRINT MODE, PAGE MARGINS AND PAGE SETTING IS POSSIBLE.
8). EXIT MENU
- CLICK EXIT TO CHANGE TO OTHER CLIENT'S FILE.
